PMC Panel

190,000.00 INC. GST

Select quantity and variation

Product Description

Whatsapp(9506637423) for Discount/Latest Price/Ac. Details

  • PAYMENT: 50% Balance before delivery against PI.
  • WARRANTY: 1 year from the date of delivery.
  • FREIGHT & INSTALLATION: INCLUDED
  • MAKE: As per specification provided.

Specification

SL NO. Item description Unit
Supply Installation and commissioning and testing of cubical type power and motor control panel with 6Nos of LED type(RYB)indicatinglamps,3 Nos of Ameter,1 No of Volt meter with selectorswich,3 No of 100/SA CTs, control fuses, control wiring etc. fabricated with 165WG MS sheet undergone powder coating painting and painted with anticorrosive primer and two coats of anamel paint to accommodate following

components including 125A TPN Aluminum busbar with emergency tripping unit contactor etc.

Job
2 63A 100MA RCBO(MCB+ELCB) NO
3 63 A 300MA RCBO(MCB+ELCB) NO
4 RCBO 4P 63 A NO
5 MCCB TPN 63 A 18KA NO
6 40A MCB TYPE C/O NO
7 10DA C/O NO
8 MCB SP 6 A NO
9 16A/20A/25A DP MCB 10KA NO
10 16A/25A TP MCB 10KA NO
11 MUSHROOM HEAD ACUATOR PUSH TURN UP WITH LEGEND STOP NO
12 3 POLE CONACTORE 25A 220V COIL NO
13 ADD-ON BLOCK {1NO+1NC NO
14 CONACTOR 3 POLE MNX9 220V COIL NO
15 ADD-ON BLOCK (1NO) NO
16 RED PUSH BOTTON NC CONTACT NO
17 GREEN PUSH BOTTON WITHNO. CONTACT NO
18 NO ELEMENT NO
19 NC ELEMENT NO
20 TERMINAL BLOCK 4 WAY NO
